Andes IP65 Bulkhead 315mm 9/14/18W CCT 3/4K 900-1800lm

Andes Bulkhead LED (White) — Power Switch 900/1400/1800lm + CCT Switch 3000K/4000K

A tough, modern bulkhead fitting designed for reliable indoor or outdoor use, with built-in flexibility to suit the job on site. This Andes bulkhead features a power-change driver (choose 9W / 14W / 18W) and a colour temperature switch (3000K warm white or 4000K neutral white), making it ideal for corridors, stairwells, exits, plant rooms, perimeter walls and general safety lighting. With IP65 weather protection, IK08 impact resistance, and a long 50,000-hour rated life, it’s a solid choice for commercial and residential installs.

Key features & benefits

• Selectable brightness: 900 / 1400 / 1800 lumens to match the space and reduce glare

• Selectable wattage: 9W / 14W / 18W via power-change driver for efficient setup

• Selectable colour: switch between 3000K (warmer) and 4000K (cleaner/whiter)

• Durable build: IP65 dust/water protection and IK08 impact rating

• Long-life LED: rated 50,000 hours (L70-B50) for low maintenance

• Clean finish: White RAL 9016 (Traffic White) suits most interiors/exteriors

• Class II (Class2): suitable where double-insulated fittings are preferred

Technical Specifications

• Code: LBA315WSCC

• Driver type: Fixed Output

• Lumen output: 900 / 1400 / 1800 lm

• Max wattage: 9W / 14W / 18W

• Efficacy: 100 lm/W

• Colour temperature: 3000K, 4000K

• CRI: >80

• Base colour: White – RAL 9016 (Traffic White)

Dimensions & Installation

• Width: 315 mm

• Height: 76 mm

• Weight: 0.67 kg

• IP rating: IP65

• IK rating: IK08

Performance & Safety

• Lifetime: 50,000 hours

• L/B at life: L70-B50

• Operating temperature: -5°C to +40°C

• E-Class: Class2

• Power factor: >0.5
